Takeuchi TB014 User Manual

150
SPECIFICATIONS
Main Specifications
TB014
Equipped with 830 mm (33 in.) Arm
Sound-power level L
WA
93 L
WA
93
Sound-pressure level L
pA
77 L
pA
78
MASS
Machine mass kg (lb.)
(not including operator)
With rubber crawlers 1410 (3110) 1525 (3360)
With steel crawlers 1460 (3220) 1575 (3470)
PERFORMANCE
Bucket capacity m
3
(cu.ft.)
(standard bucket)
Heaped 0.038 (1.33)
Struck 0.028 (0.97)
Slew speed min
–1
(rpm) 9.0 (9.0)
Ground pressure
kPa (psi)
With rubber crawlers 27.8 (4.02) 29.9 (4.34)
With steel crawlers 28.9 (4.19) 31.1 (4.51)
Travel speed km/h (mph)
1st 2.0 (1.24)
2nd 3.9 (2.42)
1st 1.9 (1.18)
2nd 3.7 (2.3)
Gradeability (degrees) 25
TYPE CANOPY CAB
Noise level dB(A)
Rubber
crawlers
Steel
crawlers
ENGINE
Manufacturer and model
Kubota D782-E2B-BHTU-1 deasel engine
Rated output kW / min
–1
(hp / rpm) 9 / 2200 (12 / 2200)
Displacement mI (cu.in.) 778 (47.5)
Starter V – kW 12 – 1.2
Alternator V – kW 12 – 0.48
Battery V – Ah 12 – 38

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
