Takeuchi TB014 User Manual

151
SPECIFICATIONS
Main Specifications
TB016
Equipped with 930 mm (37 in.) Arm
Sound-power level L
WA
93 L
WA
93
Sound-pressure level L
pA
77 L
pA
78
MASS
Machine mass kg (lb.)
(not including operator)
With rubber crawlers 1500 (3310) 1615 (3560)
With steel crawlers 1550 (3420) 1665 (3670)
PERFORMANCE
Bucket capacity m
3
(cu.ft.)
(standard bucket)
Heaped 0.038 (1.33)
Struck 0.028 (0.97)
Slew speed min
–1
(rpm) 9.0 (9.0)
Ground pressure
kPa (psi)
With rubber crawlers 26.2 (3.80) 28.0 (4.07)
With steel crawlers 27.4 (3.97) 29.3 (4.25)
Travel speed km/h (mph)
1st 2.3 (1.43)
2nd 4.2 (2.61)
1st 2.1 (1.30)
2nd 3.9 (2.42)
Gradeability (degrees) 25
TYPE CANOPY CAB
Noise level dB(A)
Rubber
crawlers
Steel
crawlers
ENGINE
Manufacturer and model Yanmar 3TNV70-STB deasel engine
Rated output kW / min
–1
(hp / rpm) 10.1 / 2200 (13.5 / 2200)
Displacement mI (cu.in.) 854 (47.8)
Starter V – kW 12 – 1.0
Alternator V – kW 12 – 0.48
Battery V – Ah 12 – 38

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
