196
OPTIONS
4. Drive in the locking pin (1) with a hammer
until it is flush with the tip of the tooth point
(2) ear.
5. The locking pin (1) is now driven in.
The same procedure can be used to install
the other tooth points.
Three-Hole Bucket
OL1L250
2
1
OL1L260
1
OL1L270
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Takeuchi TB014 and is the answer not in the manual?

Takeuchi TB014 Specifications

General IconGeneral
EngineYanmar 3TNV70
Overall Width980 mm
Transport Width980 mm
Bucket Capacity0.04 m3
Max Digging Depth2260 mm
