Tally T2040 - Paper Jam (Fanfold Paper)

➲ Paper jam (fanfold paper)
1. Open the top cover. If a paper jam should occur, then remove the
jammed paper by tearing it off at the tear off edge (the tear off edge is
located at the outfeed for the fanfold paper).
2. Press the key ↓ to transport the paper backwards (substitutes manual
knob).
3. You may support the paper return feed by cautiously pulling the
paper in the correct direction.
Before you replace the fanfold paper, refer to the instructions in the section
Inserting paper .
You should pay special attention to the following points:
Insert the paper straight.
After inserting the paper, close the tractors.
Adjust the tractors, the paper should be positioned in the tractors straight
but without tension.
Adjust the printhead gap to the paper thickness (multiple forms, etc.).
Clean upper friction (see Care and maintenance ).
