3. Check the positioning cutout part (red circle at below fig.) at the left slider section of the bridge conveying unit is fitted to red round
mark on the slider section.
■Affected machine’s serial number is below
№ Old New Parts No Parts name Q’ty
1 302LF28770
2LF28770
SHEET HINGE
STOPPER
2
(Right) (Wrong)
Clearance
4. Check whether the leverage of upper conveying guide on the bridge conveying unit is not detached.
if it is detached, add the below parts as referring the procedure mentioning next page.
【Service Bulletin】2LF-0004(B355)
Refer to the service bulletin：2LC-0034(B395)
[Conveying unit fixing]
AK eject unit
slide
rail
AK carry-in unit
Machine front
side
<AK conveying unit>
J49XX / J50XX / J51XX / J600X (2/9)
To Next Page
