b. Check the machine’s serial number whether its number is before taking the measure (use the jig to adjust the
fuser position plate) during the production.
If the machine’s serial number is before affected number, perform the corrective measure as referring to the service
bulletin No. 2LF-0003 (B345).
1) Check the fuser belt shift amount according to the content of the bulletin and
judge whether it is necessary to affix the film or not.
2) If affixing the film is necessary, affixing the film to the fuser position adjustment
plate and adjust the height.
<Affected machine’s serial number for taking the measure during the production>
a. When replacing the fuser unit, it exchanges for the fuser unit applicable to the end of the right figure.
