Electronic Safe Lock Quick Reference
The Phoenix 4.0 allows you to access our popular Electronic
Safe Lock Quick Reference right on machine. The quick
reference includes high resolution images and detailed
information for identifying, programming and drilling many
of the most common electronic safe locks. Pages are
ordered alphabetically by manufacturer. Touch and drag on
the screen to move to different areas on each the page. To
change between pages, touch the screen and SWIPE LEFT
or RIGHT in the direction of the page you’d like to navigate
to. To exit the quick reference, touch the screen and SWIPE
DOWN or tap the [X] in the top right corner.
Drill Points Abbreviations
TB = Towards Bolt TF = Toward Flat of Bolt AF = Away from Flat of Bolt
CW = Clockwise CCW = Counter-Clockwise
All Drill Points are measured from the CENTER OF THE SPINDLE HOLE
Example Drill Point Measurement:
1.5” TB, ¾” CW
