2. SPECIFICATIONS
All specifications are subject to change without notice.
Contact factory for specific model availability.
2.1. Output Rating (Duty Cycle Continuous Duty).
2.1.1. Standard Models – 10kW
1. Rated Output voltage V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
2. Rated Output current A 1000 1000 800 500 400 333 250 200 167 125 100 80 66 50 40 33 25 20 17
3. Rated Output power kW 7.5 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 9.9 10.0 10.0 9.9 10.0 10.0 10.2
2.1.2. Standard Models – 15kW
1. Rated Output voltage V N/A N/A N/A N/A N/A 30 40 50 60 80 100 125 150 200 250 300 400 500 600
2. Rated Output current A - - - - - 500 375 300 250
187.5
150 120 100 75 60 50 37.5 30 25
3. Rated Output power kW - - - - - 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0
2.2. Input Characteristics
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Input voltage/freq. (range) --- 208VAC (180-253), 400VAC (342-440), 480VAC (432-528), all 47-63Hz
2. # of phases --- 3 Phase (Wye or Delta) 4 wire total (3 Phases and 1 Protective Earth ground)
3. Dropout voltage V 175/338/425
4. Input current 180/342/432 VAC A 10kW – 45/23/20, 15kW – 64/32/27; All at full rated Output power.
5. Power Factor (typical) --- 0.88 Passive (208VAC, 400VAC, 480VAC)
6. Efficiency at Low Line, 100% load % 77 min for 7.5kW, 83 min for 10kW, 88 min for 15kW
7. Inrush current A Not to exceed full rated Input current
8. Leakage current mA 3.5 (EN60950-1) max
9. Input Protection --- Circuit breaker for 7.5V, 10V and 12.5V Outputs @ 10kW with 208VAC input.
10. Fuse --- Fuse for: 7.5V, 10V and 12.5V Outputs @ 10kW with 400VAC/480VAC input.
Fuse for: 20V ≤ Vout ≤ 600V @ 10kW/15kW with 208VAC/400VAC/480VAC input.
11. Input Overvoltage Protection Unit shall not be damaged by line overvoltage with maximum duration of 100uSec. Up to 120% of nominal
AC input voltage.
12. Phase Imbalance % ≤ 5% on Three Phase Input
2.3. Static Characteristics
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Max. line regulation, CV --- 0.1% of FS from lo(min) to
lo(max).
0.01% of FS from lo(min) to lo(max).
2. Max. line regulation, CC --- 0.1% of FS from Vo(min) to
Vo(max).
0.05% of FS from lo(min) to lo(max).
3. Max load regulation, CV --- 0.1% of FS from lo(min) to
lo(max).
0.02% of FS lo(min) to lo(max).
4. Max load regulation, CC --- 0.1% of FS from Vo(min) to
Vo(max).
0.075% of FS from Vo(min) to Vo(max).
5. Temperature Stability, CV --- +/- 0.05% of Vo(rated) over 8 hours after 30 minute warm up (constant Line, Load & Temperature).
6. Temperature Stability, CC --- +/- 0.05% of Io(rated) over 8 hours after 30 minute warm up (constant Line, Load & Temperature).
7. Temperature Coefficient, CV PPM/C 200 (0.02% of Vo(rated)/Degree C)
8. Temperature Coefficient, CC PPM/C 300 (0.03% of Io(rated)/Degree C)
9. Output noise p-p (20MHz), CV mV 60 60 60 60 60 60 60 75 75 100 100 125 150 175 200 200 300 350 350
10. Ripple r.m.s 5Hz1MHz, CV
mV 20 20 20 20 20 20 20 20 20 25 25 25 25 35 35 60 60 60 60
11. Ripple r.m.s 5Hz1MHz, CC (10kW)
mA 5300 4000 2560 1000 640 444 250 160 67 50 40 32 26 20 16 13 10 8 7
12. Ripple r.m.s 5Hz1MHz, CC (15kW)
mA - - - - - 350 200 150 100 100 100 50 50 20 20 20 10 10 10
13. Rem. sense compensation/wire V 1 1 1 1 1 1.5 2 3 3 4 5 5 5 5 5 5 5 5 5
*Ripple and Noise at Vo(rated) and rated load at 25°C, nominal AC input, per EIJ RC9002A
