2.6. Remote Analog Control And Signals
1. Vout voltage programming ---
0100%, 05V or 010V, user selectable. Accuracy & Linearity +/-1% of Vo(rated).
2. Iout voltage programming ---
0100%, 05V or 010V, user selectable. Accuracy & Linearity +/-1% of Io(rated).
3. Vout resistor programming ---
0100%, 05/10kohm full scale, user selectable. Accuracy & Linearity +/-1% of Vo(rated).
4. Iout resistor programming ---
0100%, 05/10kohm full scale, user selectable. Accuracy & Linearity +/-1% of Io(rated).
5.Shut-Off control (SO) --- By voltage: 0.6V = Disable, 2-15V = Enable (default) or Dry Contact: Open = Enable, Short = Disable, user
selectable logic
6. Output current monitor ---
05V or 010V, user selectable, Accuracy +/-1%
7. Output voltage monitor ---
05V or 010V, user selectable, Accuracy +/-1%
8. Power supply OK signal (PS_OK) --- Yes. TTL high = OK, 0V = Fail / Output OFF (500ohm series resistance)
9. Single-Wire Parallel operation --- Up to four (4) identical units may be connected in Basic or Advanced Master/Slave Mode with Single-Wire
connection for Output Voltage Models where 7.5V ≤ Vout ≤ 25V (10kW).
In Advanced Parallel mode, the Master displays the calculated (not actual) Output current for the combined
parallel combination on the front panel and is made available via the digital interface. Remote analog
current of the Master unit is scaled to its actual Output current (only).
10. Two-Wire Parallel operation --- Up to four (4) identical units may be connected in Basic or Advanced Master/Slave mode with Two-Wire
connection for Output Voltage Models where 25V ≤ Vout ≤ 600V (10kW/15kW).
Same Operation as Single-Wire in Advanced Parallel mode.
11. Series operation --- Possible (with external diodes), up to identical 2 units with total Output voltage not to exceed +/-600V from
chassis ground.
12. CV/CC signal ---
CV: TTL high (45V), Max source current = 10mA, CC: TTL low (0.00.4V), Max sink current = 10mA
13. Enable/Disable --- Dry contact. Open: Off, Short: On. Maximum voltage at Enable/Disable In = 6V
14. Remote/Local Control --- Selects Remote or Local operation by Voltage: 0-0.6V = Local, 2-15V = Remote.
15. Remote/Local signal --- Open collector: Local = Open (Maximum voltage = 30V), Remote = On (Maximum sink current 10mA)
