3.4. Rack Mounting
The Genesys
TM
Power Supply Series is designed to fit in a standard 19” equipment rack.
3.4.1. To Install the Power Supply in a Rack:
3.4.1.1. Use the front panel rack-mount brackets to install the Power Supply in the
rack.
3.4.1.2. Use a support bar to provide adequate support for the rear of the Power
Supply. Do not obstruct the air exhaust at the rear panel of the unit.
3.4.2. Rack Mount Slides (optional, customer provided)
Use rack-mount slides (General Devices P/N C230-S-122 or equivalent) to install the
unit in a standard 19” wide equipment rack. For racks with longer depth, contact the
rack-mount slide provider for the proper rack-mount slide to use.
To install the unit into a standard 19” wide equipment rack, refer to rack-mount slide-to-
unit assembly instructions. Use four M5x0.8-8mm long (max) pan head screws to
attach a slide to one side of the unit. To prevent damage, use the specified screw
length only (8mm max.).
3.5. Location, Mounting and Cooling
This Power Supply is fan cooled. The air intake is at the front panel and the exhaust is at
the rear panel. Upon installation, allow cooling air to reach the front panel ventilation
inlets. Unrestricted air space at the front and the rear of the unit is necessary for proper
cooling of Power Supply.
The Power Supply should be used in an area where the ambient temperature does not
exceed +50°C.
3.6. AC Source Requirements
The Genesys
TM
Series 10kW/15kW power supply can be operated from a nominal three-
phase 208VAC, 400VAC or 480VAC, 4 wire, 47–63 Hz AC input. The AC input voltage
range and current required for each model is specified in Chapter 2, Section 2.2 (Input
Characteristics). Ensure that under heavy load, the AC voltage supplied to the Power
Supply does not fall below the specifications described in Chapter 2, Section 2.2 (Input
Characteristics).
3.7. AC Input Power Connection
CAUTION
Connection of this Power Supply to an AC power source should be made
by an electrician or other qualified personnel. Do not exceed the torque
specified on the AC Input stud terminals.
WARNING
There is a potential shock hazard if the Power Supply chassis (with
cover in place) is not connected to an electrical safety ground via
the safety ground of the AC input threaded-stud terminals.
CAUTION
Ensure that the screws used to attach the slides are not longer than 8mm.
