2.12. EMC
CE Mark
1. ESD --- EN61000-4-2 (IEC 1000-4-2): Air-disch. +/-8kV, contact disch. +/-4kV
2. Fast transients --- EN61000-4-4 (IEC 1000-4-3): +/-2kV: AC Power, 2kV: DC Output
3. Surge immunity --- EN61000-4-5 (IEC 1000-4-5): 1kV line-to-line, 2kV line-to-ground
4. Conducted immunity --- EN61000-4-6 (IEC 1000-4-6): 10Vrms
5. Radiated immunity --- EN61000-4-3 (IEC 1000-4-3): 10V/m
6. Power Frequency Magnetic Field --- EN61000-4-8: 30A/m
7. Conducted emission --- EN55011A, FCC part 15J-A
8. Radiated emission --- EN55011A, FCC part 15J-A
Note: EMC Approval for: Vout < 30V @ 208VAC/400VAC
30V ≤ Vout ≤ 600V @ 208VAC/400VAC/480Vac
2.13. Safety
1. Applicable Standards --- UL/cUL 60950-1, EN60950-1 recognized (CB Scheme)
All Outputs are Hazardous.
For Vout ≤ 400VDC: IEEE, LAN, IS510 or IS420 are SELV.
CE mark for all inputs (208VAC, 400VAC, 480VAC).
2. Insulation resistance --- 100Mohm at 500Vdc, 25°C, 70% Relative Humidity
