95
83532002 Rev C
9. ISOLATED ANALOG PROGRAMMING OPTION
9.1. Introduction
Isolated Analog Programming is an internal option card for Remote Analog programming of
the Genesys
TM
power supply series. The option is factory installed and cannot be obtained
with IEMD or LAN Interfaces. Output Voltage and Current Limit can be programmed and
read back through optically isolated signals which are isolated from all other ground
references in the power supply.
There are two types of Isolated Analog programming cards:
a) 0-5V/0-10V option (P/N: IS510): Using 0-5V or 0-10V signals for programming and
readback.
b) 4-20mA option (P/N: IS420): Using current signals for programming and readback.
9.2. Specifications
9.2.1. 0-5V/0-10V Option (PN: IS510)
Programming
Inputs
Output voltage programming accuracy % +/-1
Output current programming accuracy % +/-1
Output voltage programming temperature coefficient ppm/°C +/-100
Output current programming temperature coefficient ppm/°C +/-100
Input impedance Ohm 1M
Absolute maximum voltage VDC 0-15
Max. voltage between program inputs and supply outputs VDC 600
Monitoring
Outputs
Output voltage monitoring accuracy % +/-1.5
Output current monitoring accuracy % +/-1.5
Output Impedance (see Note) Ohm 100
Max. voltage between monitoring outputs and supply outputs VDC 600
NOTE:
Use 100kohms minimum input impedance for the monitoring circuits to minimize the readback error.
9.2.2. 4-20mA Option (PN: IS420)
Programming
Inputs
Output voltage programming accuracy % +/-1
Output current programming accuracy % +/-1
Output voltage programming temperature coefficient ppm/°C +/-100
Output current programming temperature coefficient ppm/°C +/-100
Input impedance Ohm 1M
Absolute maximum input current VDC 0-15
Max. voltage between program inputs and supply outputs VDC 600
Monitoring
Outputs
Output voltage monitoring accuracy % +/-1.5
Output current monitoring accuracy % +/-1.5
Maximum load impedance Ohm 100
Max. voltage between monitoring outputs and supply outputs VDC 600
