2.4. Protective Functions
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. OCP %
0 100%
2. OCP Type --- Constant current
3. Knee point protection --- None, No damage at knee point operation
4. Short circuit protection --- Yes
5. Foldback protection --- Output shut down when power supply changes from CV to CC mode, manual reset by front panel OUT
button or Digital Communication, user-selectable.
6. Foldback response time S Min = 0.25/Max = 25, Default = 0.25
Settable via “FBD” command using Digital Communication command.
7. OVP Type --- Inverter shut-down, manual reset by AC input recycle, by front panel OUT button, Remote Analog or Digital
Communication command.
8. OVP programming accuracy % +/- 5% of Vo(rated)
9. OVP adjustment method --- Adjust by front panel Voltage encoder and Digital Communication command.
10. OVP trip point V 5% to 105% of Vo(rated) and shall always be greater than 105% of the Output voltage setting.
Default = 105% of Vo(rated)
11. OVP response time mS Less than 10mS for Output voltage to begin to drop.
12. Max. OVP reset time S 7 (from AC On/Off switch turn On)
13. Output Under Voltage limit --- Prevents adjusting Output voltage below limit.
Preset by the front panel or Digital Communication command.
0-95% of Vo(rated) and shall always be less than 95% of the Output voltage setting.
Raises the PS_OK signal when Vout is below limit.
Does not affect J1 Remote Analog programming.
Default = 0V.
14. Input Under Voltage protection --- Yes, power supply shutdown below AC Input low line (non-latching).
15. Over Temperature protection --- Unit shall shut down when internal temperature exceeds safe operating levels. (Latched in Safe-mode and
unlatched in Auto-mode).
16. Phase Loss Protection Yes, power supply shutdown after phase-loss detection (non-latching).
2.5. Dynamic Characteristics
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Up-prog. Response time, 0-Vo(rated),
full-load
mS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
2. Up-prog. Response time, 0-Vo(rated),
no load
mS 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50
3. Down-prog response time full-load mS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
4. Transient response time (CV mode)
mS
Less than 3. Time for Vo to recover to within 2% of Vo(rated) for a load change of 50 to 100% or 100 to
of Io(rated).
5. Time for Output Stable S 2 maximum, from Enable Output until Output stable (within 2% of steady-state).
6. Output fall and rise --- Overshoot limited to 125% Rated Output. Voltage at No-Load, Full-Load, Resistive Load.
7. Start-Up delay S Less than 7 (without IEEE option installed)
Note: Items 2.5.1 through 2.5.7 with resistive load.
