TEC MA-1595-1 SERIES - ECR Technical Specifications

16. SPECIFICATIONS EO1-11152
16. SPECIFICATIONS
16- 1
16. SPECIFICATIONS
Size ........................................................ 460 mm (width) x 430 mm (depth) x 350 mm (height)
(height including rubber feet)
Weight ................................................... 15.0 kg
Power Required .................................... AC 117 V ±10 %; 60 Hz
(varies depending on the destination)
Power Consumed ................................. 0.6 A at 117 V
Ambient Temperature .......................... 0 °C to 40 °C, 10% to 90% Relative Humidity
Size of Receipt and Journal Tape ...... Width: 57.5 ± 0.5 mm
Thickness: 0.06 mm to 0.075 mm
Outside dimension: 83 mm or less
Recommended thermal paper: KF50 (KANZAN)
TF50KS-E2C (Nippon Paper Industries)
P350 (KSP)
Paper specification: Only paper rolled onto a core is
acceptable, however, the paper end
should not be pasted to the core.
