6. PROGRAMMING OPERATIONS EO1-11152
6.1 Basic Key Functions and Keyboard Variations in Programming Operations
6- 3
2) All Function keys ([C], [@/FOR], [ST], [AT/TL], [DP#], etc.) must be operated on the ECR keyboard.
3) In the following operations, however, the Character Setting Sheet should be removed and the keys on
the PK-2 are used as PLU Preset-code Keys:
• PLU PRESET-CODE KEY SETTING (Submode 27 in this chapter)
Case 2: When the ECR Keyboard is Flat Keyboard Type:
The Flat Keyboard will be set with the “Setting Mode Key Layout” in the programming operations including
character entries. On this keyboard, functions and locations of keys required in various programming
operations are fixed. Characters on the key sheet can be entered directly through this keyboard. The
Character Code Entry method is also allowed.
NOTE: If an option keyboard (PK-2) is connected, the DIRECT CHARACTER ENTRY method is allowed
through both the ECR keyboard and the option keyboard.
To Next Page
