Protocol type:
RAW
ASCII
For details look into the TECMP
Bit Rate: Choose the bit rate. Recommended rates are:
Slow: 2400 bps
Medium: 9600 bps
Fast: 19200 bps
Number of Bits:
5 bits (only available in Protocol type raw)
6 bits (only available in Protocol type raw)
7 bits
8 bits
9 bits (only available in Protocol type raw)
It is depended of connected device on this port
Parity Type:
None
Odd
Even
Mark
Space
It is depended of connected device on this port
Stop Bits:
1 bit
2 bits
It is depended of connected device on this port
Message Delimiter:
LF(10/0x0A)
Other
It is depended of connected device on this port
Max Packet Size: Possible values are between 64 and 1500. It is maximum size of one
TECMP-frame, which collects received messages on this port (one TECMP frame for
more than one RS 232 message.
For details see the TECMP-definition.
Rx Timeout: After this time the TECMP-frame is sent, even if the Max packet size is not
reached.
