Figure 5-2: Schematic with MediaGateway
Figure 5-3: Example of MediaGateway and Capture Module (CM_ETH_Combo) assembly
Connect the Ethernet Cable to the Converter or to the MediaGateway (FIGURE 5-5) and
that device to our CM device (FIGURE 5-4).
