Technicolor TD5130 Setup & User Guide

11
SETUP & USER GUIDE
Copyright © 2012 Technicolor. All rights reserved.
DMS-CTC-20120508-0000 v1.0.
3.3 Windows 7
If you are using Windows

7, follow the instructions below to configure your computer.
1
Click Start > Control Panel > Network & Sharing Center.
2
Click Local Area Connection.
3
Click Properties.
4
On the network components list, make sure that Internet
Protocol (TCP/IP)
is checked. If not, check it to enable the
Properties button.
5
Select Internet Protocol (TCP/IP), and then click
Properties.
6
On the General tab, select Obtain an IP Address
automatically and Obtain DNS server address
automatically.
7
Click OK.
General Page

Technicolor TD5130 Specifications

General

Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
ADSL Standards	ANSI T1.413 Issue 2
ADSL2 Standards	ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+ Standards	ITU G.992.5 Annex A
Wireless	802.11b/g
Ethernet Ports	4 x 10/100
USB Ports	1 x USB 2.0
VoIP	No
Security	WEP, WPA, WPA2
