Technicolor TD5130 Setup & User Guide

21
SETUP & USER GUIDE
Copyright © 2012 Technicolor. All rights reserved.
DMS-CTC-20120508-0000 v1.0.
5.2 System Configuration
The System Configuration page allows you to configure the Internet service and the system date and
time, and enable web browsing interception.
To view the System Configuration page, click Technicolor Gateway > Configuration.
To modify the system configuration, click Configure.
5.2.1 DSL Service Configuration
To modify the DSL service configuration, click Configuration Wizard and then follow the instructions on
the screen. See “Configuration Wizard on page 14”.
5.2.2 Date and Time Configuration
To modify the time configuration, do the one of following:
Manual Configuration
To manually set the date and time, enter the date and time values in the corresponding fields. Select a
Timezone or enable Summer Time for applicable areas.
Auto Configuration
To synchronize the date and time with a time server, do the following:
1 Check the Auto-configuration box.
2 Enter the values of the applicable items in your location:

Timezone — Enter the time zone in your location.

Summer Time — Check if summer time is applicable in your location.
3 Enter the time server to sync the Wireless Gateway with. You can type up to five timer servers.
4 Click Apply to save changes.

Technicolor TD5130 Specifications

General

Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
ADSL Standards	ANSI T1.413 Issue 2
ADSL2 Standards	ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+ Standards	ITU G.992.5 Annex A
Wireless	802.11b/g
Ethernet Ports	4 x 10/100
USB Ports	1 x USB 2.0
VoIP	No
Security	WEP, WPA, WPA2
