Appendix C Specifications
IC
▪
Main chip: RTL8672-VK
▪
AFE: RTL8271B-VR
▪
Ethernet: RTL8305N-GR
▪
WiFi: RTL8188RE-GR
▪
DDR1: 32MB
▪
Flash: 4 MB Serial
User Interface
▪
ADSL2+: POTS
▪
1x1 11n 2.4GHz single band
▪
4x 10/100 Base-T Ethernet LAN ports
Buttons
▪
1 x Power ON/OFF button
▪
1 x WPS button
▪
1 x Reset to default button
LEDs
Front panel
▪
Power LED
▪
Ethernet LED
▪
Wi-Fi LED
▪
WPS LED
▪
ADSL LED
▪
Internet LED
Back panel
▪
4 x Ethernet LEDs
IO Ports
▪
1 x RJ-11 DSL connector
▪
4 x RJ-45 Ethernet connector
▪
1 x DC In jack
Antenna
Standard: 1 internal printed antenna
Reserved: 1 IPEX connectors
for external dipole antenna connection
DC inputs
12
VDC 1A
Temperature
Operating: 0
°C ~ 40° C
Storage:
-10°c ~ 70°C
Humidity
Operating: 10% ~ 9
5%, RH, no condensation
PCB
Dimensions
142 x 117
x 1.6 mm
