AccuLoad IV Installation & Maintenance Manual
Meter I/O Connections 52
4.3.2 Meter Inputs for QT and SA Models
Refer to the following tables regarding meter inputs for the QT and SA models.
Table 34: Three-Product Meters (AccuLoad Models ST and N4)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8
Single Pulse M1A M2A M3A Pgm Pgm Pgm Pgm Pgm
Dual Pulse M1A M1B M2A M2B M3A M3B Pgm Pgm
Dual pulse with integrity n/a n/a n/a n/a n/a n/a n/a n/a
Table 35: Two-Product Meters (AccuLoad Models ST and N4)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8
Single Pulse M1A M2A Pgm M4A Pgm Pgm Pgm Pgm
Dual Pulse M1A M1B M2A M2B Pgm Pgm Pgm Pgm
Dual pulse with integrity M1A M1B M1A M1B M2B M2B M2A M2B
Table 36: One-Product Meters (AccuLoad Models ST and N4)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8
Single Pulse M1A Pgm Pgm Pgm Pgm Pgm Pgm Pgm
Dual Pulse M1A M1B Pgm Pgm Pgm Pgm Pgm Pgm
Dual pulse with integrity M1A M1B M1A M1B Pgm Pgm Pgm Pgm
Table 37: Six-Product Meters (AccuLoad IV QT and SA Models)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8 In #9 In #10 In #11 In #12 In #13 In #14
Single
pulse
M1A M2A M3A Pgm Pgm Pgm Pgm Pgm M4A M5A M6A Pgm Pgm Pgm
Dual
pulse
M1A M1B M2A M2B M3A M3B Pgm Pgm M4A M4B M5A M5B M6A M6B
Dual/
integrity
n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Table 38: Five-Product Meters (AccuLoad IV QT and SA Models)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8 In #9 In #10 In #11 In #12 In #13 In #14
Single
pulse
M1A M2A M3A Pgm Pgm Pgm Pgm Pgm M4A M5A M6A Pgm Pgm Pgm
Dual
pulse
M1A M1B M2A M2B M3A M3B Pgm Pgm M4A M4B M5A M5B Pgm Pgm
Dual/
integrity
n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
