AccuLoad IV Installation & Maintenance Manual
Meter I/O Connections 53
4.4 Additive Meters and Digital Inputs
The A4I module provides 10 inputs that can be used for either additive meter pulse inputs or as DC digital
inputs and 20 AC digital outputs. The AC digital outputs are wired using the same method shown for the
A4M and A4B modules. However, the meter pulse and DC digital inputs are wired differently on the A4I
module, as illustrated in the following diagrams.
Table 39: Four-Product Meters (AccuLoad IV QT and SA Models)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8 In #9 In #10 In #11 In #12 In #13 In #14
Single
pulse
M1A M2A Pgm Pgm Pgm Pgm Pgm Pgm M3A M4A Pgm Pgm Pgm Pgm
Dual
pulse
M1A M1B M2A M2B Pgm Pgm Pgm Pgm M3A M3B M4A M4B Pgm Pgm
Dual/
integrity
n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Table 40: Three-Product Meters (AccuLoad IV QT and SA Models)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8 In #9 In #10 In #11 In #12 In #13 In #14
Single
pulse
M1A M2A Pgm Pgm Pgm Pgm Pgm Pgm M3A Pgm Pgm Pgm Pgm Pgm
Dual
pulse
M1A M1B M2A M2B Pgm Pgm Pgm Pgm M3A M3B Pgm Pgm Pgm Pgm
Dual/
integrity
M1A M1B M1A M1B M2A M2B M2A M2B M3A M3B M3A M3B Pgm Pgm
Table 41: Two-Product Meters (AccuLoad IV QT and SA Models)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8 In #9 In #10 In #11 In #12 In #13 In #14
Single
pulse
M1A M2A Pgm Pgm Pgm Pgm Pgm Pgm M3A Pgm Pgm Pgm Pgm Pgm
Dual
pulse
M1A M1B M2A M2B Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm
Dual/
integrity
M1A M1B M1A M1B M2A M2B M2A M2B Pgm Pgm Pgm Pgm Pgm Pgm
Table 42: One-Product Meters (AccuLoad IV QT and SA Models)
In #1 In #2 In #3 In #4 In #5 In #6 In #7 In #8 In #9 In #10 In #11 In #12 In #13 In #14
Single
pulse
M1A Pgm Pgm Pgm Pgm Pgm Pgm Pgm M3A Pgm Pgm Pgm Pgm Pgm
Dual
pulse
M1A M1B Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm
Dual/
integrity
M1A M1B M1A M1B Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm Pgm
