TechniSat DIGITRADIO 143 CD User Manual

3.3 Connection
> The audio outputs audio out analogue (18), optical out digital (20) or coaxial out digital (21) are available on the back
of the device to connect an A/V amplifier or a stereo system.
> Connect the supplied aerial antenna to the antenna connection (23).
> Depending on whether you wish to use the LAN connection or the WLAN connection, connect the LAN cable for your
network to the LAN connection (22), or raise the WLAN antenna (17).
> Then insert the mains cable into a 110-240V ~ 50/60Hz mains outlet.
3.4 Switching on/o
> To switch on the DIGITRADIO 143 CD, press the on/standby buon on the device (15) or on the remote control (14).
> To switch o, press the on/standby buon on the device (15) or on the remote control (14) again.
3.5 Source selection
> Press the MODE buon on the device (5) or on the remote control (8) repeatedly to scroll through the available sources.
Alternatively:
> Open the submenu in the current source by pressing the MENU buon and select >Main menu.
The source currently selected is shown on the display.
3.6 Adjusting the volume
> Rotate the volume knob (15) on the device to the right or press the VOL+ (23) buon on the remote control to increase
the volume. Rotate the volume knob (15) on the device to the le or press the VOL- (10) buon on the remote control
to reduce the volume.
The set volume is shown on the display while it is being adjusted.
18

TechniSat DIGITRADIO 143 CD Specifications

General

Package weight	3600 g
Package depth	130 mm
Package width	500 mm
Package height	340 mm
Disc types supported	CD, CD-R, CD-RW
Optical drive included	Yes
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1.7 W
Power consumption (typical)	15 W
Audio formats supported	MP3
HDMI in	-
Audio (L/R) in	1
Headphone connectivity	3.5 mm
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Display	TFT
Apple docking	No
Product color	Black
Display resolution	240 x 320 pixels
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM, UKW
Internet radio services supported	Spotify
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	290 mm
Width	435 mm
Height	75 mm
Weight	2750 g
