TechniSat DIGITRADIO 143 CD User Manual

45
EN
FR
IT
NL
PL
CZ
SK
The entered password is now verified. This process is generally completed in a few seconds and the WLAN connection
can now be used.
14.2.2.2 Configuration via the WPS function
This establishes a direct connection to the router. Selecting and/or entering a WLAN network (SSID) and password is not
required.
> Start the WPS function on your router as per the instruction manual.
> Then select [PBC WLAN structure] to launch the connection process.
Please observe the display overlays. The connection process is generally completed in a few seconds and the WLAN
connection can be used.
14.2.2.3 Manual configuration
> Select [Manual seings] then [Wireless] to launch manual configuration.
> Now select whether to allow automatic retrieval of the IP address, gateway etc. from your router (DHCP active) or if you
would like to enter this manually (DHCP inactive).
Please take into account that automatic retrieval of the IP address, gateway, subnet mask only works if the DHCP function
is activated in your router.
> One by one, enter the IP address, subnet mask, gateway address, primary DNS and secondary DNS if required, using the
Arrow buons on the remote control. Confirm each set value with the OK buon.
> Now enter the name (SSID) of your WLAN network using the virtual keyboard and confirm with OK.
> Select whether your WLAN network is Open, encrypted by WEP or by WPA/WPA2 and confirm the following item.
> Continue to use the virtual keyboard to enter your WLAN password and confirm with OK to start the connection process.
In general, the WLAN connection can be used aer a few seconds.

TechniSat DIGITRADIO 143 CD Specifications

General

Package weight	3600 g
Package depth	130 mm
Package width	500 mm
Package height	340 mm
Disc types supported	CD, CD-R, CD-RW
Optical drive included	Yes
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1.7 W
Power consumption (typical)	15 W
Audio formats supported	MP3
HDMI in	-
Audio (L/R) in	1
Headphone connectivity	3.5 mm
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Display	TFT
Apple docking	No
Product color	Black
Display resolution	240 x 320 pixels
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM, UKW
Internet radio services supported	Spotify
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	290 mm
Width	435 mm
Height	75 mm
Weight	2750 g
