8 The DAB function
DAB+ is a digital format through which crystal clear sound with no noise can be heard. In contrast to conventional analogue
radio stations, DAB+ can be used to broadcast multiple stations on the same frequency. You can find further information, for
example, at www.dabplus.de or www.dabplus.ch.
8.1 DAB radio reception
> Press the MODE buon as oen as required until [DAB Radio] appears on the display.
Alternatively:
> Press the MENU buon and then select Main menu > DAB.
If you are in a submenu, first of all select the main menu as described in section 3.7.
If DAB is being started for the first time, a complete station scan is performed. The station list is then shown (see Section
8.3).
8.2 Performing a station scan
The automatic scan [Complete scan] scans all DAB Band III stations and thereby finds all stations being broadcast
within the reception range.
Aer ending the scan, the first station in alphanumeric order will be played.
> In order to perform a complete scan, press the SCAN buon. [Scan] appears on the display. The scan starts and the
progress bar appears on the display.
> When completed, press p or q and OK to select a station.
Alternatively:
> Press the MENU buon and use p or q to select > Complete scan. Confirm by pressing OK.
If no station is found, check the antenna position and change the location if required. Check whether digital radio
stations are being broadcast in your area.

TechniSat DIGITRADIO 143 CD Specifications

General

Package weight	3600 g
Package depth	130 mm
Package width	500 mm
Package height	340 mm
Disc types supported	CD, CD-R, CD-RW
Optical drive included	Yes
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1.7 W
Power consumption (typical)	15 W
Audio formats supported	MP3
HDMI in	-
Audio (L/R) in	1
Headphone connectivity	3.5 mm
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Display	TFT
Apple docking	No
Product color	Black
Display resolution	240 x 320 pixels
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM, UKW
Internet radio services supported	Spotify
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	290 mm
Width	435 mm
Height	75 mm
Weight	2750 g
