TechniSat DIGITRADIO 143 CD User Manual

35
EN
FR
IT
NL
PL
CZ
SK
11 Audio input
You can play sound from an external device via the DIGITRADIO 143 CD.
> Connect the external device to the Audio input (19) on the DIGITRADIO 143 CD.
> Press the MODE buon as oen as required until [Line in] is shown on the display.
Alternatively:
> Press the MENU buon and then select Main menu > Line in.
For an optimum volume seing, use the volume control on the radio, as well as the one on the connected device.
Take into account that, when the volume seing is very low on the connected device and the volume seing on the radio
is higher, irritating noises/murmurs are amplified accordingly and can be heard more clearly. It is recommended that you
set the volume on the DIGITRADIO 143 CD on a DAB+ or USW station, for example, switch to audio input and then adjust
the volume on the connected device in such a way that the overall volume of the audio input corresponds approximately
to the volume of the DAB+/USW station. In this way you can also avoid considerable volume dierences when switching
between functions on the DIGITRADIO 143 CD.
12 CD/MP3 player
12.1 General information on CDs/MP3 CDs
The device is designed for music CDs that are played with audio data (CD-DA or MP3 for CD-R and CD-RW). MP3 formats must
be created with ISO 9660 Level 1 or Level 2. Multi-session CDs cannot be read.
In MP3 mode, the terms "Folder" = Album and "Track" are critical. "Album" corresponds to the folder on the PC, "title" of the file
on the PC or a CD-DA track. The device sorts the albums or the tracks of an album into alphabetical order by name. If you prefer
a dierent order, change the name of the track or album and place a number in front of the name.
When burning a CD-R and CD-RW with audio data, various problems can arise which could occasionally compromise smooth
playback. This is caused by faulty soware and hardware seings or the blank disc being used. Should such errors arise, you
should contact your CD burner/burner soware manufacturer or search for the relevant information, e.g. on the Internet.

TechniSat DIGITRADIO 143 CD Specifications

General

Package weight	3600 g
Package depth	130 mm
Package width	500 mm
Package height	340 mm
Disc types supported	CD, CD-R, CD-RW
Optical drive included	Yes
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1.7 W
Power consumption (typical)	15 W
Audio formats supported	MP3
HDMI in	-
Audio (L/R) in	1
Headphone connectivity	3.5 mm
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Display	TFT
Apple docking	No
Product color	Black
Display resolution	240 x 320 pixels
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM, UKW
Internet radio services supported	Spotify
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	290 mm
Width	435 mm
Height	75 mm
Weight	2750 g
