TechniSat DIGITRADIO 143 CD User Manual

55
EN
FR
IT
NL
PL
CZ
SK
17 Technical data
Reception channels DAB/DAB+, USW, Bluetooth, Internet, Spotify Connect, USB, CD, network drive
LAN
WLAN/Bluetooth frequencies
LAN: 10/100
WLAN 802.11b, g, a, n, 2412 - 2472 MHz (max. +20dBm EIRP), 5180 - 5700MHz (max.
+19.5dBm EIRP)
Bluetooth: V4.2+EDR, 2402 - 2480 MHz (max. 4dBm Class II)
L2CAP/A2DP
Display 3.2" TFT colour display
WLAN encryption WEP, WPA, WPA2, WPS
DAB frequencies 174 - 240 MHz
USW frequencies 87.5 - 108 MHz
Power supply 110-240V ~ 50/60Hz
Power consumption Operation: ~5.5W
Standby: <1W
Connections Analogue Audio-Out RCA L+R, Analogue Audio-In RCA L+R, Digital Optical and Coaxial,
3.5 mm headphone jack, LAN jack, USB jack, antenna F connector WLAN antenna
connection
Favourites memory slots DAB/DAB+: 30
USW: 30
Internet: 30
Spotify Connect: 10
Operating temperature 0° - 40°C
Dimensions mm (W x D x H) 435 x 275 x 77

TechniSat DIGITRADIO 143 CD Specifications

General

Package weight	3600 g
Package depth	130 mm
Package width	500 mm
Package height	340 mm
Disc types supported	CD, CD-R, CD-RW
Optical drive included	Yes
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1.7 W
Power consumption (typical)	15 W
Audio formats supported	MP3
HDMI in	-
Audio (L/R) in	1
Headphone connectivity	3.5 mm
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Display	TFT
Apple docking	No
Product color	Black
Display resolution	240 x 320 pixels
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM, UKW
Internet radio services supported	Spotify
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	290 mm
Width	435 mm
Height	75 mm
Weight	2750 g
