TechniSat DIGITRADIO 143 CD User Manual

51
EN
FR
IT
NL
PL
CZ
SK
16.2 Problems with USB media
Symptom Possible cause/remedy
No playback possible. The device is not in USB mode.
Switch to the respective source using MODE.
Medium not inserted or empty.
Insert the medium correctly or
provide it with music data.
16.3 Problems with the remote control
Symptom Possible cause/remedy
The remote control does not work. Baeries are inserted incorrectly or are low.
Check the polarity.
Change the baeries.
IR connection interrupted.
Remove objects located between
the remote control and the device.
Distance too great.
Max. distance from the device: approx. 4 metres

TechniSat DIGITRADIO 143 CD Specifications

General

Package weight	3600 g
Package depth	130 mm
Package width	500 mm
Package height	340 mm
Disc types supported	CD, CD-R, CD-RW
Optical drive included	Yes
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	1.7 W
Power consumption (typical)	15 W
Audio formats supported	MP3
HDMI in	-
Audio (L/R) in	1
Headphone connectivity	3.5 mm
Receiver type	stereo
Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
Display	TFT
Apple docking	No
Product color	Black
Display resolution	240 x 320 pixels
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM, UKW
Internet radio services supported	Spotify
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Depth	290 mm
Width	435 mm
Height	75 mm
Weight	2750 g
