FM, Airband and Shortwave Antennas
For receiving FM, airband and shortwave broadcasts, you can either use the telescopic antenna or an
external antenna.
When using the telescopic (internal) antenna, push the [ INT ANT. / EXT ANT. ] switch to ANT.” ● the “INT
position. The display shows “INT” to indicate that the telescopic antenna is selected. Changing the length
and angle of the telescopic antenna can improve the reception.
Internal (telescopic) antenna selected
External antenna selected
● When using an antenna , push the switch to “EXT ANT.” position. external for FM, airband or shortwave the
The display shows “EXT” to indicate that the external antenna is selected. On the right side of the radio,
there are three external antenna sockets:
1) Low-impedance 50 BNC socket for FM and airband antennas. A 50 or 75 coaxial cable can
be used to a suitable antenna.connect
2) Low-impedance 50 BNC socket for shortwave (SW) antennas. A 50 or 75 coaxial cable can
be used to a suitable antenna.connect
Ω
Ω
Ω
Ω
