Tektronix MDO3000 Series Program Manual

Getting Started
Table 1-1: Updates to the MDO3000 and MDO4000C Series Oscilloscopes (cont.)
Feature Use these comm ands
Video Picture functionality (standard on MDO 3000). Requires
the DPO4VID application module for use with MSO/DPO4000B
and MDO4000/B/C models)
VIDPic:AUTOContrast
VIDPic:AUTOContrast:UPDATERate
VIDPic:BRIGHTNess
VIDPic:CONTRast
VIDPic:DISplay
VIDPic:FRAMETYPe
VIDPic:LOCation:HEIght
VIDPic:LOCation:OFFSet
VIDPic:LOCation:STARt:LINE
VIDPic:LOCation:STARt:PIXel
VIDPic:LOCation:WIDth
VIDPic:LOCation:X
VIDPic:LOCation:Y
VIDPic:SOUrce
VIDPic:STANdard
Dual edge trigger/search functionality TRIGger:A:EDGE:SLOpe
SEARCH:SEARCH<x>:TRIGger:A:EDGE:SLOpe
FastAcq™ high-speed waveform acquisition mode
New color palettes (Temperature, Spectral, Normal, Inverted)
ACQuire:FASTAcq:STATE
ACQuire:FASTAcq:PALEtte
Digital Channel Activity Monitor DISplay:DIGital:ACTIVity
Additional calibration status queries
CALibrate:INTERNal:STATus:RF?
CALibrate:INTERNal:STATus:SCOPE?
CALibrate:RESults:FACtory:AFG ?
CALibrate:RESults:FACtory:RF?
CALibrate:RESults:FACtory:SCOPE?
CALibrate:RESults:SPC:RF?
CALibrate:RESults:SPC:SCOPE?
Additional configuration queries
(AFG, ARB, DVM, and VidPic are available for MDO3000 and
MDO4000C series. VidPic requires the DPO4VID application
module on the MSO/DPO4000B and MDO4000/B/C models)
CONFIGuration:AFG?
CONFIGuration:APPLications:CUSTOMMask?
CONFIGuration:APPLications:STANDARDMask?
CONFIGuration:APPLications:VIDPIC?
CONFIGuration:ARB?
CONFIGuration:DVM?
Math vertical autoscale feature MATH[1]:AUTOSCale
Total overshoot measurement type
MEASUrement:IMMed:TYPe
MEASUrement:MEAS<x>:TYPe
1-6 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
