Menus
SPG600 & SPG300 Sync Pulse Generators User Manual 3-35
ALARM RESET. Resets the alarm status. The sync pulse generator holds the alarm
status even if the cause of the alarm is eliminated. Use this menu item when you
need to reset the status. If the cause of the error is not eliminated, the alarm status
is set again when you reset the status.
GPI ALARM OUTPUT. Enables or disables the alarm signal output. Use the left (
W)
or right (
X) arrow button to select between Disable and Enable. When enabled, an
alarm signal is output on pin 1 of the GPI connector. Press the ENTER button to
confirm the selection.
System Information
Submenu
This menu allows you to display the system information. Use the up (S) or down
(
T) arrow button to scroll through the menu. Figure 3-22 shows the System
information submenu diagram.
Figure 3-22: System information submenu diagram
Select Information in the SYSTEM PARAMETER menu item
: FPGA VERSION (STD)
A:1.0 D:1.0
: FPGA VERSION (OPT)
A:1.0 D:1.0
: F/W VERSION
1.0.0
: OPTION KEY
ABCDEFGHIJKLMNOPQRST
: S/N
J310000
To Next Page
