Appendix A: Specifications
A-6 SPG600 & SPG300 Sync Pulse Generators User Manual
Table A-8: AC power source
Characteristic Performance requirement Reference information
Rating voltage 100 V to 240 V, 50/60 Hz
Voltage range 90 V to 250 V, 50/60 Hz
Power consumption SPG600: 85VA, 35W
SPG300: 65VA, 30W
Surge current < 20 A: SPG600 and SPG300
Table A-9: Clearance
Characteristic Performance requirement Reference information
Side 5 cm (2 in)
Rear 7.5 cm (3 in)
Table A-10: Mechanical characteristics
Characteristic Description
SPG600
Dimensions See Figure A-1.
Height 43.6 mm (1.7 in)
Width 482.5 mm (19.0 in)
Depth 557.5 mm (21.9 in)
Net weight Approximetely 6 kg (with rack rail)
SPG300
Dimensions See Figure A-2.
Height 43.6 mm (1.7 in)
Width 206.2 mm (8.1 in)
Depth 435.7 mm (17.2 in)
Net weight Approximetely 2.5 kg
