SPG600 & SPG300 Sync Pulse Generators User Manual 3-45
Factory Default Settings
Table 3-8 lists the instrument factory default settings. These settings can be
recalled by selecting Factory Default from the PRESET : RECALL menu item
in the System menu.
Table 3-8: Factory default settings
Menu item name Settings
Video menu
ANALOG SYNC (STD) Black Burst
ANALOG SYNC (OPT) Black Burst
TEST SIGNAL (ANALOG) SMPTE Color Bars
TEST SIGNAL (SDI) SMPTE Color Bars
TIMING (ANALOG)
VERTICAL 0 Line
HORIZONTAL 0.0000
µsec
FINE (Option 01 only) 0.0 nsec
TIMING (SDI)
VERTICAL 0 Line
HORIZONTAL 0.0000
µsec
OVERLAY
Blink OFF
OVERLAY: LOGO
Logo OFF
X 0.0 %APH
Y 0.0 %APH
OVERLAY: ID TEXT
Status Disable
X 10.0 %APH
Y 80.0 %APH
PA R AM ET ER
COMPONENT Y, Cb, Cr
PRECISION 10-bit
EDH Enable
