Appendix A: Specifications

A-8 SPG600 & SPG300 Sync Pulse Generators User Manual

Figure A-2: SPG300 dimensions

206.2 mm (8.1 in)

43.6 mm

(1.7 in)

15.4 mm

(0.6 in)

13.5 mm

(0.5 in)

422.2 mm

(16.6 in)
