!sEcl
Second
I
ms
I Millisecond
~
Microsecond
Special-Purpose
Keys
Refer
to
Figure
2-9
for
the
locations
of
the
spe-
cial-
purpose
keys.
CE
ON
/
Off
6419-14
Figure
2-9.
Special
purpose
keys.
I ENTER I
Key-Enters
an
instruction
that
ends
with
a
numeric
entry.
I CE I
Key-Clears
the
last
command
entry
of
an
instruction
with
each
keystroke
.
2-12
I
I ON
/O
FF I
Key-
Turns
Channel 1 and
Chan-
nel 2 displays on
or
off
when
the
selected
In-
put
Coupling
switch
is
not
in
the
OFF
position
.
The I
ON/OFF
I key is also
used
to
remove
signal
processing
results
from
the
display.
I SHIFT I
Key-Activates
a
second
function
of
a
dual-function
key.
The
I
SHIFT
I key
must
be
pressed
first
before
selecting
the
second
function
of
a
dual-function
key.
The
second
function
is
indicated
by
the
character(s)
on
the
side
of
the
key .
Data
Readout
The
data
readout
fields display Channel 1 ,
Chan-
nel 2,
save
reference
,
and
signal
processing
re-
su
lts
.
The
data
readout
display
shows
the
horizon-
tal
timing
,
trigger
,
setups
,
and
the
channel
wave
form
measurement
results.
Channel 1
readout
fields
are
shown
across
the
top
of
the
dis-
play
area,
and
the
Channel
2
and
save
reference
readout
fields
are
shown
at
the
bottom
of
the
dis-
play
area.
Save
reference
readout
fields
are
dis-
played
directly
above
the
Channel 2
readout
fields
when a
saved
waveform
is
displayed.
Signal
proc-
essing
readout
fields
are
displayed
directly
above
the
save
reference
data
field .
Figure
2-1
O
shows
the
locations
of
the
Channel 1
and
Channel 2
readout
fields .
The
number
of
fields
needed
to
display all
the
data
available
exceeds
the
width
of
the
display
area.
To
view all
the
data
,
the
fields
must
be
scrolled
hori
-
zontally. The
data
readout
fields
may
also
be
verti-
cally
positioned
within
the
display
area.
Scrolling
and
vertical
positioning
are
described
in
"Operat-
ing
the
Instrument"
in
Section
4.
The
description
of
the
channel
data
readout
fields
are
from
left
to
right
as follows :
-
Controls,
Connectors,
Indicators
-
2-13
