TCP305 and TCP312 Performance Verification
5-20
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Instruction Manual
Required Test Equipment
To perform the acceptance tests in this section, you will need the test equipment
listed in Table 5--11. The test equipment must meet or exceed the specifications
listed. The test procedures may need to be modified if the recommended
equipment is not used.
Table 5- 11: Required test equipment
Qty Item Description
Recommended
equipment
1 Oscilloscope 500 MHz bandwidth Tektronix TDS5000
1 Current Probe Ampl ifier Tektronix TCPA300
1 Leveled Sine Wave Generator 3 MHz to 100 MHz Wavetek 9100 with Option 250
1 High Amplitude Pul s e Generator Rise time <1 ns, pulse width
>100 ns,amplitude >5 V
p-p
into 50 Ω
Picosecond Labs 2600
1 Digital Multimeter DCV: 0.1% accuracy 5
1
/
2
digit resolution Keithley 2700
1 Current Source DCA: 0.1% accuracy, 0 to ±10 A Wavetek 9100
1 HF Current Loop 50 Ω, BNC Connector Tekt ronix part number 015-0601-50
1 DC Current Loop 5 turns 18 AWG coated wire Refer t o page 5--4
1 Precision Termination 50 Ω, ±0.1%, 0.5 W Tektronix part number 011-0129-00
1 BNC Cable 50 Ω, 0.76 m (30 in) long Tekt ronix part number 012-0117-00
1 Cable TEKPROBE Interface Cable Tektronix part number 012-1605-00
1 Adapter BNC-to-Dual Banana Tektronix part number 103-0090-00
