Specifications
4-10
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Instruction Manual
Insertion Z (ohms)
1.0
.1
.01
.001
10k 100k 1M 10M 100M
Frequency (Hz)
TCP303
100µ
10µ
Insertion Z (ohms)
10m
1m
10 100 1k 10k 100k
Frequency (Hz)
1M
100m
TCP404XL
10M
Insertion Z (ohms)
1.0
.1
.01
.001
10k 100k 1M 10M 100M
Frequency (Hz)
TCP312
Insertion Z (ohms)
1.0
.1
.01
.001
10k 100k 1M 10M 100M
Frequency (Hz)
TCP305
Figure 4- 6: Insertion impedance graphs for the current probes
