Tektronix TCPA300 SERIES - TCP305 Current Probe Test Record

TCP305 and TCP312 Performance Verification
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Instruction Manual
5-29
TCP305 Current Probe Test Record
Photocopy this form and use it to record the performance test results.
TCP305 test record
Instrument Serial Number: Certificate Number:
Temperat ure: Relative Humidity %:
Date of Cal ibration: Technician:
Performance test Range, A/V
Test
current, A
Minimum Measured/calculated Maximum
DC Gain Accuracy (% Error) 5A/V 1.00 A -- 3 % +3%
/
3.00 A -- 3 % +3%
5.00 A -- 3 % +3%
10 A/V 2.00 A -- 3 % +3%
/
6.00 A -- 3 % +3%
10.00 A -- 3 % +3%
Rise Time 5A/V -- -- -- ≤7ns
Bandwidth 5A/V .707 -- -- -- -- -- --
