TCP305 and TCP312 Performance Verification
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Instruction Manual
5-27
Make or verify the equipment settings in Table 5--15.
Table 5- 15: Equipment settings for bandwidth
Oscilloscope
Vertical input impedance 50 Ω
Time base 200 ns/division
Record length 500
Coupling DC
Offset 0 V (mid-scale)
Trigger type Edge
Trigger mode Auto
Trigger position 50%
Acquisition mode Average
Number of waveforms to average 8
Measurement type Peak-to-Peak
Leveled sine wave generator
Frequency 3MHz
Amplitude 3V
p-p
TCPA300
Coupling DC
1. Do not clamp the current probe around any conductor, but make sure the
jaws are locked shut.
2. Press the amplifier PROBE DEGAUSS AUTOBALANCE button. Wait for
the degauss/autobalance routine to complete before proceeding. The routine
is complete when the indicator light turns green.
3. Clamp the current probe around the H F current loop.
4. Enable the output of the leveled sinewave generator.
5. Verify the output level is what is listed for the probe in Table 5--16.
6. Using the peak-peak measurement capability of the oscilloscope, measure
the peak-peak reading and record it in Table 5--16 as M
1
.
Equipment Sett ings
Procedure
