Getting Started
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Instruction Manual
1-7
Travel Case
The travel case is a recommended accessory for the TCPA300/400 Amplifiers.
The travel case includes room to store one amplifier and two TCP300/400 Series
Current Probes, one of each size. (For example, you can store a TCP305 and a
TCP303 probe.) A compartment is included to store associated cables and
terminations. See Figure 1--3 for the proper location of the equipment.
Cables &
terminations
Probe holders
Small current
probe
Instruction
manual
Amplifier
Large current
probe
Figure 1- 3: Equipment locations in the travel case
