TCP303 and TCP404XL Adjustments
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes Instruction Manual
6-15
Table 6- 9: Settings for transient response and preliminary gain adjustments (Cont.)
Oscilloscope
Time Base 100 s/division, Auto
triggered
Vertical Input 50 Ω
Record Length 500
Coupling DC
Offset 0V
Trigger
Type Edge
Mode Auto
Position 10%
Acquisition Mode Average
Number of Wave-
forms
8
Measurement Ty pe Risetime, Amplitude
AC current source (TCP303 only)
Frequency 1 kHz square wave
Amplitude 0.3 A pk
High amplitude pulse generator (TCP404XL only)
Pulse Width 250 s
Pulse R epetit ion Fre-
quency
20 Hz
Amplitude 5Ap-p
