Tektronix TDS2000C series User Manual

Appendix A: Specifications
Table 5: Trigge
rSpecifications
Characteristic Description
Trigger Source Sensitivity (Measurement style A) Sensitivity (Measurement style B)
All Products
1.5 div from DC to 10 MHz
(>2 mV/div)
4 div from DC to 10 MHz (2 mV/div)
1 div from DC to 10 MHz (>2 mV/div)
2.5 div from DC to 10 MHz
(2 mV/div)
TDS1001C-EDU
3 div between 10 MHz and 40 MHz 1.5 div between 10 MHz and
40 MHz
TDS1002C-EDU
3 div between 10 MHz and 60 MHz 1.5 div between 10 MHz and
60 MHz
TDS2001C
3 div between 10 MHz and 50 MHz 1.5 div between 10 MHz and
50 MHz
TDS2002C, TDS2004C
3 div between 10 MHz and 70 MHz 1.5 div between 10 MHz and
70 MHz
TDS1012C-EDU,
TDS2012C, TDS2014C
3 div between 10 MHz and 100 MHz 1.5 div between 10 MHz and
100 MHz
Channel Inputs
TDS2022C, TDS2024C
3divbetween10MHzand200MHz
1.5 div from 10 MHz to 100 MHz
2.0 div above 100 MHz to 200 MHz
EXT
300 mV from DC to 100 MHz
500 mV from 100 MHz to 200 MHz
(TDS2022C and TDS2024C)
200 mV from DC to 100 MHz
350 mV from 100 MHz to 200 MHz
(TDS2022C and TDS2024C)
Sensitivity, Edge-Type
Trigger, DC Coupled
EXT/5 1.5 V from DC to 100 MHz
2.5 V from 100 MHz to 200 MHz
(TDS2022C and TDS2024C)
1 V from DC to 100 MHz
1.75 V from 100 MHz to 200 MHz
(TDS2022C and TDS2024C)
The typ ical sensitivities are as follows:
Trigger Source Sensitivity
AC Same as DC Coupled limits for frequencies 50 Hz and above
NOISE REJ Effective in Sample or Average Mode, >10 mV/div to 5 V/div. Reduces DC Coupled trigger sensitivity by 2X.
HF REJ
Same as DC Coupled limits from DC to 7 KHz.
Sensitivity, Edge-Type
Trigger, non-DC
Coupled, typical
LF REJ
Same as DC Coupled limits for frequencies above 300 KHz.
The settable resolution for the trigger level is 0.02 division for an input channel source, 4 mV for an Ext source, and 20 mV for an
Ext/5 source.
Input channels
±8 divisions from center screen
EXT ± 1.6 V
Trigger Level Ranges,
typical
EXT/5
±8V
±(0.2 div +5 mV) for signals within ±4 divisions from center screen, having
rise and fall times of >20 ns
EXT
±(6% of setting + 40 mV) for signals less than ±800 mV
Trigger Level Accuracy,
DC Coupled, typical
EXT/5 ±(6% of setting + 200 mV) for signals less than ±4 V
Lowest Frequency for
Successful Operation
of “Set Level to 50%”
Function, typical
50 Hz.
Trigger Mode Auto
Default Settings for
Video Trigger
Trigger Coupling AC
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual 111
