Appendix B: TPP0101 and TPP0201 Series 10X Passive Probes Information
Optional Acce
ssories
You can order the following accessories for your probe .
Accessory Part num ber
Alligator Ground Lead, 12 in
196-3512-xx
6” Clip-on Ground Lead
196-3198-xx
Ground Spring, Short, 2 ea.
016-2034-xx
MicroCKT Test Tip
206-0569-xx
Micro Hook Tip 013-0363-xx
Universal IC Cap
013-0366-xx
Circuit Board Test Point/PCB A dapter
016-2016-xx
Wire, spool, 32 AWG
020-3045-xx
Specifications
Table 7: Electrical and mechanical specifications
Characteristic TPP0101 TPP0201
Bandwidth (–3 dB) DC to 100 MHz DC to 200 MHz
System attenuation accuracy 10:1 ± 3.2% 10:1 ±3.2%
Compensation range
TPP0101:
15 pF – 25 pF
TPP0201:
15 pF – 25 pF
System input resistance
@DC
10 MΩ ±1.5% 10 M Ω ±1.5%
System input capacitance
<12 pF <12 pF
System rise time (typical)
<3.5 ns <2.3 ns
Propagation delay ~6.1 ns ~6.1 ns
Maximum input voltage
300 V
RMS
CAT II 300 V
RMS
CAT II
Cable length
1.3 m 1.3 m
Table 8: Environmental specifications
Characteristics Description
Temperature
Operating
Nonoperating
–10 °C to +55 °C (14 °F to +131 °F)
–51 °C to +71 °C (–60 °F to +160 °F)
Humidity
Operating and
Non-Operating
5% to 95% relative humidity (%RH) up to +30 °C (86 °F), 5% to
65% RH above +30° C up to + 55 °C (131 °F)
Altitude
Operating
Nonoperating
3.0 km (10,000 ft) maximum
12.2 km (40,000 ft) maximum
118 TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
