USB Flash Drive and Device Ports
File format Extension Comments
RLE RLE
Run-length encoding; this format uses a
lossless compression algorithm.
TIFF TIF Tagged Image File Format
Before you can save data to the USB ash drive, you must change the print button
to the alternative Save function. To do so, select the Save/Recall Save All
PRINT Button Saves Image to File option. The Save LED adjacent to the
print butt
on lights to indicate the alternative function.
To save a screen image to a USB ash drive, follow these steps:
1. Insert a USB ash drive into the USB Flash Drive port.
2. To change the folder d esignated as the current folder, push the Select Folder
option button.
3. Access the screen you want to save.
4. Push the
print (Save) button.
The osc
illoscope saves the screen image and automatically generates the
le name.
To see
a list of the les created by the Save Image To File function, you can
access the Utility File Utilities menu.
USB Device Port
You can use a USB cable to connect the oscilloscope to a PC, or to a PictBridge
compatible printer. The USB Device port is on the rear of the oscilloscope.
USB D evice port
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual 69
