Tektronix TDS2000C series User Manual

Appendix A: Specifications
Table 6: Genera
l Specifications
Characteristic
Description
Display
Display Type
11.5 cm (W) x 8.64 cm (H), 14.38 cm diagonal, ¼ VGA, active TFT color liquid crystal display (LCD) with color
characters/waveforms on a black background. Surface anti-glare (3H) treatment
Display Resolution 320 horizontal by 240 vertical pixels
The video display comprises both the character and waveform displays.
Brightness, typical
400 cd/ m
2
typical, 320 cd/m
2
min.
Probe Compen sato r Output
Probe Compensator, Output
Voltage and Frequency, typical
Characteristics are as follows:
Output voltage 5.0 V ±10% into 1 Meg Ω load
Frequency 1 kHz
Power Source
Source Voltage Full Range: 100 to 240 VAC RMS ±10%, Installation Category II (Covers range of 90 to 264 VAC)
Power Consumption Less than 30 W at 85 to 275 VAC input.
Environmental
Operating 0° C to +50° C, with 5° C/minute
maximum gradient, non-condensing,
up to 3000m altitude
Temperature
Nonoperating
-40° C to +71° C, with 5° C/minute
maximum gradient
Cooling Method Convection cooled
Operating: 5% to 85% relative humidity (% RH) at up to +40° C
5% to 45% RH above +40° C up to +50° C, non-condensing, and as limited by a
Maximum Wet-Bulb Temperature of +37° C (derates relative humidity to 45 % RH at
+50° C)
Humidity: Operating and
Non-Operating
Non-Operating: 5% to 85% RH (Relative Humidity) at up to +40° C,
5% to 45% RH above +40° C up to +50° C, non-condensing.
Above +50° C limited by a Maximum Wet-Bulb Temperature of +37° C (derates
relative humidity to 12% RH at +71° C)
Operating: Up to 3000 meters (10,000 feet)Altitude: Operating and
Non-Operating
Non-Operating: Up to 3000 meters (10,000 feet).
Altitude is limited by possible damage to LCD at higher altitudes. This damage is
independent of operation
Mechanical
Requirements that follow are nominal:
Height
158.0 mm ( 6.22 in.)
Width
326.3 mm (12.85 in)
Overall Dimensions
Depth
124.1 mm (4.88 in)
Requirements that follow are nominal:
Stand alone instrument 2.0 kg (4.4 lbs)
With accessories
2.2kg(4.9lbs)
Weight
When packaged for domestic shipment 3.6 kg (8 lbs)
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual 113
