Command Descriptions
2- 260
TDS200, TDS1000/2000, TDS1000B/2000B, TPS2000 Programmer
Table 2- 31: Additional WFMPre commands (Cont.)
Command DescriptionArgument
WFMPre:ZUNit <QString> Z-axis units
WFMPre:ZZEro <NR3> Z-axis origin offset
WFMPre:<wfm>? (Query Only)
Returns the waveform formatting data for the waveform specified by
<wfm>, if that waveform is active or displayed. If that waveform is
not active or displayed, the query fails and the oscilloscope generates
event message 420 (Query unterminate d) and 2244 (waveform
requested is not active).
Waveform
WFMPre:<wfm>? (Refer to Waveform Mnemonics on page 2-10
for more information.)
Returns the response in the foll owing format:
:WFMPre:<wfm>:WFID <Qstring>;PT_FMT { ENV|Y};
XINcr <NR3>;PT_Off <NR1>;XZEro <NR3>;XUNit <QString>;
YMUlt <NR3>;YZEro <NR3>;YOFF <NR3>;YUNit <QString>;
NR_Pt <NR1>
WFMPre:<wfm>:NR_Pt? (Query Only)
NOTE. This query is not avai lable when using a TDS210 or TDS220
oscilloscope (firmware below V 2.00) with a TDS2CMA communica-
tions module.
Group
Syntax
Returns
