ELF System
Copper / Fiber :: ELF Family
The following illustrations show a typical installation.
Figure 2 - Installing ELF Chassis on a Rack
Figure 3 - Grounding an ELF Chassis
1.3.2 Wall-Mount ELF Chassis Bracket (ELF-0000-0900)
Telect’s Wall-Mount ELF Chassis Bracket is designed
to hold one ELF Chassis (ELF-0000-2400) against a
wall or side of a cabinet. The chassis bracket allows
an ELF chassis with either rear- and/or front-access
modules to either extend from a wall or cabinet using
a minimum wall “footprint” or to hug the wall or cabinet
with a minimum prole. Wall-mounting hardware is
not included.
Figure 4 - Bracket
