ELF System
Copper / Fiber :: ELF Family
Figure 39 - Example of Model ELF-9716-1700 nished cable and wiring
5.3 ELF 12 x 4 Alarm Pin Block Module (Model ELF-0005-0001)
Alarm I/O Cross-Connects
Jumper
Tie-Down
Bar
ELF 12 x 4 Alarm Pin Block
Alarm Interconnects
(Model ELF-0005-0001)
2.26
(57.4)
5.88
(149.4)
1.63 (41.3)
Figure 40 - Model ELF-0005-0001 Parts & Dimensions
