Telect ELF-9716-1900 - Figure 10 - ELF Lockable Wall-Mount Dimensions

© Telect, Inc., All Rights Reserved, 124317-10 A0
1.509.926.6000 :: telect.com
12
ELF System
Copper / Fiber :: ELF Family
10 (0.39) Dia.
134
(5.28)
4.6 (.18) Dia.
7.6 (0.3) Dia.
76.2 (3.00)
135 (5.31)
63.5
(2.50)
3.00
(0.12)
Note: Dimensions are in mm (in.)
FRONT VIEW
TOP VIEW
REAR VIEW
(ROTATED)
9.0 (0.35)
4.6 (.18)
9.4 (0.37)
38.1 (1.5)
172.9
(6.81)
236.79 (9.32)
Figure 10 - ELF Lockable Wall-Mount Dimensions
