ELF System
Copper / Fiber :: ELF Family
ELF Module Conguration ELF Model
Number
Page Illustration
DSX-1
8-Termination REAR — Wire-Wrap I/O
FRONT — Wire-Wrap XC
• 3-Port Bantam Patch Jacks
ELF-1008-1100 17
REAR — BNC I/O
FRONT — Wire-Wrap XC
• 3-Port Bantam Patch Jacks
ELF-1008-1200 19
REAR — RJ48C I/O
FRONT — Wire-Wrap XC
• 3-Port Bantam Patch Jacks
ELF-1008-1800 21
6-Termination
(See Note.)
TOTAL FRONT ACCESS —
• Wire-Wrap I/O
• Wire-Wrap XC
• 3-Port Bantam Patch Jacks
ELF-3006-1100 23
TOTAL FRONT ACCESS —
• RJ48C I/O
• RJ48C XC
• 3-Port Bantam
Patch Jacks
ELF-3006-1800 24
DNI-1
NOTE: All DS1 and DS3 Total Front Access and 12x4 Alarm Pin Block ELF Modules t Telect’s ELF
Wall Bracket (ELF-000-0600).
